3mm round piranha led

Series No:

BL-FL7670

Weight:(g/pcs)

0.25

Dimension:(mm)

7.6 x 7.6 x 4.4

Package:

Specification:

download

Inquiry

Description:

Enhancing Electronics with 3mm Round Piranha LEDs: The Ultimate Thru-Hole Solution

In the vast universe of electronic components, the 3mm round Piranha LED emerges as a beacon of innovation and efficiency. Known for its compact size and intense brightness, this LED variant, synonymous with “thru hole” and “LED Piranha 3mm,” has become a staple in the design and manufacturing of electronic devices. This article aims to shed light on the unique features, wide-ranging applications, and the myriad benefits of 3mm round Piranha LEDs, also referred to as “piranha light” or “3mm through hole LED,” providing insights through case studies and user testimonials. Tailored for electronics manufacturers, engineers, purchasers, and administrators, this piece encapsulates the transformative potential of these LEDs in the electronics sector.

The Significance of 3mm Round Piranha LEDs

3mm round Piranha LEDs stand out in the LED market for their compact design and powerful performance. These thru-hole components are prized for their ease of integration into various circuits, offering a blend of durability and luminosity that is hard to match.

Diverse Features and Applications

High-Intensity Illumination: Despite their small size, 3mm round Piranha LEDs pack a significant punch in terms of brightness, making them ideal for applications where space is limited but high visibility is required.

Wide Range of Applications: From consumer electronics to automotive dashboards, and from decorative lighting to signaling devices, these LEDs provide versatile solutions across industries.

Advantages of Employing 3mm Round Piranha LEDs

Energy Efficiency: One of the key benefits of these LEDs is their ability to deliver high luminosity while consuming minimal power, aligning with the global trend towards energy conservation.

Longevity and Reliability: Designed to withstand rigorous use, 3mm round Piranha LEDs offer a longer lifespan compared to standard LEDs, reducing the need for frequent replacements and maintenance.

Real-World Impact: Case Studies and User Testimonials

Case Studies: An examination of their use in traffic signal lights reveals significant improvements in energy efficiency and maintenance costs, demonstrating the practical benefits of integrating these LEDs into public infrastructure.

User Testimonials: Feedback from electronics professionals consistently highlights the superior performance and reliability of 3mm round Piranha LEDs in a variety of applications, from bespoke consumer gadgets to industrial-grade machinery.

Conclusion: The Bright Future of 3mm Round Piranha LEDs

The 3mm round Piranha LED is not just a component; it’s a testament to the advancements in LED technology. As industries continue to seek efficient, reliable, and compact lighting solutions, the popularity and application of these LEDs are set to grow exponentially.

Call to Action: Embrace the future of electronics with the innovative 3mm round Piranha LEDs. Elevate your projects to new heights of efficiency and design with the leading thru-hole solution today.

3mm round piranha led
3mm round piranha led

Features

  • 3mm Round Super Flux LED Lamp: These LEDs, often called Piranha LEDs due to their shape, are characterized by their round head and larger soldering pads, which provide better heat dissipation and stability.
  • Dimensions: Measuring 7.62 x 7.62 x 4.0 mm, these LEDs are compact yet offer high brightness and durability.
  • Wide Viewing Angles: The design of these LEDs allows for a wide viewing angle, making them ideal for applications where visibility from different angles is crucial.
  • Ideal for Backlight and Indicator: Due to their wide viewing angle and high brightness, they are well-suited for use as backlights in various devices and as indicators in control panels, dashboards, and more.
  • RoHS Compliance: Adherence to the Restriction of Hazardous Substances Directive ensures that these LEDs are manufactured without certain hazardous materials, making them environmentally friendly.

Applications

  • Backlighting in Electronics: Commonly used for backlighting in LCD displays, keypads, and control panels due to their even light distribution.
  • Indicator Lights: Ideal for use in electronic devices, automotive dashboards, and machinery as indicator lights, offering clear visibility.
  • Decorative Lighting: Employed in decorative lighting applications due to their bright light and wide viewing angle, suitable for both indoor and outdoor use.
  • Signage and Displays: Used in signage, billboards, and display boards for their durability and high visibility.
  • Consumer Electronics: Incorporated into consumer electronics for status indicators, backlighting screens, and buttons.
  • Automotive Lighting: Applied in automotive lighting for interior and exterior lights, including dashboard illumination and signal lights.

RoHs Compliance, Pb-free              Anti-Static Attention

Electrical-optical characteristics:
Filters Sort results
Reset Apply
Article No
color
material
wavelength
apperance
v_typ
v_max
luminous_min
luminous_typ
degree
BL-FL7670BGC
Ultra Bluish Green
InGaN
505
Water Clear
4.2
800
4200
50
BL-FL7670PGC
Ultra Pure Green
InGaN
525
Water Clear
4.2
1000
5200
50
BL-FL7670UBC
Ultra Blue
InGaN
470
Water Clear
4.2
800
2200
50
BL-FL7670UEC
Ultra Orange
AlGaInP
630
Water Clear
2.5
800
1600
50
BL-FL7670UGC
Ultra Green
AlGaInP
574
Water Clear
2.5
200
800
50
BL-FL7670URC
Ultra Red
AlGaAs,DDH
660
Water Clear
2.2
600
1100
50
BL-FL7670UWC
Ultra White
InGaN
-
Water Clear
4.2
1000
5200
50
BL-FL7670UYC
Ultra Yellow
AlGaInP
590
Water Clear
2.5
600
1400
50
Package configuration & Internal circuit diagram
3mm round  piranha led


All dimensions are in millimeters(inches)
Tolerance is +-0.25(0.01″) unless otherwise note
Specifications are subject to change without notice.

Partno description:

LEDs, Light Emitting diodes, which include various small kinds, such as 3mm, 5mm, 8mm, 10mm; round type, rectangular type square type, tower type, Oval led, elliptical, flat top; SMDs, high power led, piranha LEDs

Part No of  LED diode

More Information

Lens Color:

CodeDTCWE
Meaningcolor DiffusedColor TintedWater ClearWater DiffusedOrange diffused

Absolute maximum ratings (Ta=25°C)

ParameterSRLRURUEUYUGPGBGBUBUVWUnit
Forward Current I F252525303030303030303030mA
Power Dissipation P d606060656575110110120120120120mW
Reverse Voltage V R555555555555V
Peak Forward Current I PF (Duty 1/10 @1KHZ)150150150150150150150100100100100100mA
Operation Temperature T OPR-40 to +80°C
Storage Temperature T STG-40 to +85°C
Lead Soldering Temperature T SOL  Max.260+-5°C for 3 sec Max. (1.6mm from the base of the epoxy bulb)°C
Related Information

Applied for:
auto lampcameradome lightrgb screentraffic light



The LEDs described here are intended to be used for ordinary electronic equipment (such as office equipment,

communication equipment and household applications). Consult Betlux’s Sales in advance for information on

applications in which exceptional reliability is required, particularly when the failure or malfunction of the LEDs

 may directly jeopardize life or health (such as in aviation, transportation, traffic control equipment, medical

and life support systems and safety devices).

CAUTIONS for Through-Hole LED Lamps

1. Application
The LEDs described here are intended to be used for ordinary electronic equipment (such as office equipment, communication equipment and household applications). Consult Betlux’s Sales in advance for information on applications in which exceptional reliability is required, particularly when the failure or malfunction of the LEDs may directly jeopardize life or health (such as in aviation, transportation, traffic control equipment, medical and life support systems and safety devices).

2. Storage
The storage ambient for the LEDs should not exceed 30℃ temperature or 70% relative humidity. It is
recommended that LEDs out of their original packaging are used within three months
For extended storage out of their original packaging, it is recommended that the LEDs be stored in a sealed
container with appropriate desiccant or in a desiccator with nitrogen ambient.

3. Cleaning
Use alcohol-based cleaning solvents such as isopropyl alcohol to clean the LED if necessary

4. Lead Forming & Assembly
During lead forming, the leads should be bent at a point at least 3mm from the base of LED lens. Do not use
the base of the leadframe as a fulcrum during forming.
Lead forming must be done before soldering, at normal temperature.
During assembly on PCB, use minimum clinch force possible to avoid excessive mechanical stress.

led diode formingassembly notice of led diode

Soldering

When soldering, leave a minimum of 2mm clearance from the base of the base of the lens to the soldering point. Dipping the lens into the solder must be avoided.

Do not apply any external stress to the lead frame during soldering while the LED is at high temperature.

Recommended soldering conditions:



IR Reflow Soldering (for SMD display)Wave SolderingSoldering Iron
Pre-Heat150-180°CPre-Heat100°C Max.Temperature300°C Max.
Pre-Heat Time120sec Max.Pre-Heat Time60sec Max.
Peak Temperature260°C Max.SolderWave260°C Max.Soldering Time3sec Max.(one time only)
Soldering Time10 sec Max.Soldering Time5sec Max.

Note: Excessive soldering temperature and/or time might result in deformation of the LED lens or failure of the LED

ESD(Electrostatic Discharge)

Static Electricity or power surge will damage the LED.

Suggestions to prevent ESD (Electrostatic Discharge):

n Use a conductive wrist band or anti-electrostatic glove when handling these LEDs

n All devices, equipment, and machinery must be properly grounded

n Work tables, storage racks, etc. should be properly grounded

n Use ion blower to neutralize the static charge which might have built up on surface of the LED’s

 plastic lens as a result of friction between LEDs during storage and handling

ESD-damaged LEDs will exhibit abnormal characteristics such as high reverse leakage current,

low forward voltage, or “no light on” at low currents. To verify for ESD damage, check for “light on”

and Vf of the suspect LEDs at low currents.

The Vf of “good” LEDs should be>2.0V@0.1mA for InGaN product and >1.4V@0.1mA for AlInGaP

 product.

antistatic notice-smd led

Drive Method

An LED is a current-operated device. In order to ensure intensity uniformity on multiple LEDs connected in

parallel in an application, it is recommended that a current limiting resistor be incorporated in the drive circuit,

 in series with each LED as shown in Circuit A below.

drive notice - led diode

When selecting power for LED systems, it’s essential to understand several key parameters to ensure safe operation, longevity, and optimal performance. Here are some steps and considerations for LED power selection:

  • Determine the Forward Voltage (Vf) of the LED(s):

Each LED has a forward voltage, which is the voltage at which the LED operates when the current is flowing through it. This value can typically be found in the LED’s datasheet.

  • Determine the Forward Current (If) of the LED(s):

The forward current is the current at which the LED is designed to operate. Running an LED at higher than its rated current can reduce its lifespan and increase the heat it produces.

  • Decide on the Configuration:

Series Configuration: When LEDs are connected in series, the forward voltages add up, but the current remains the same.

Parallel Configuration: When LEDs are connected in parallel, the forward voltage remains the same, but the currents add up. This configuration can be risky because if one LED fails or has a slightly lower forward voltage, it can cause the other LEDs to draw more current.

Calculate Total Power Requirements:

Power (W) = Total Forward Voltage (V) x Total Forward Current (A)

For example, if you have three LEDs connected in series, each with a forward voltage of 3V and a forward current of 20mA, the total power requirement would be:

Power = (3V + 3V + 3V) x 20mA = 9V x 0.02A = 0.18W

  • Select an Appropriate Power Supply:
  • Voltage Rating: The power supply voltage should match or slightly exceed the total forward voltage of your LED configuration.
  • Current Rating: The power supply’s current rating should meet or exceed the total forward current of your LED configuration.
  • Safety Margin: It’s a good practice to select a power supply that can provide at least 20% more power than your calculated requirement. This ensures the power supply isn’t operating at its maximum capacity, which can extend its life and ensure safer operation.
  • Consider Additional Features:
  • Dimming Capability: If you want to control the brightness of your LEDs, choose a power supply with dimming capabilities.
  • Overcurrent and Overvoltage Protection: To protect your LEDs, select a power supply with built-in protection mechanisms.
  • Thermal Management: Ensure that the power supply has adequate cooling, especially if it will be enclosed or in a location with limited airflow.
  • Regulation and Efficiency:A power supply with good regulation will maintain a consistent voltage output despite variations in the load. High efficiency ensures minimal power is wasted as heat.
  • Physical Size and Form Factor:Depending on where you plan to place the power supply, its size and shape may be critical factors.

In summary, when selecting power for LED systems, understanding your LED’s requirements and the configuration you plan to use is essential. Then, pick a power supply that meets those needs with some added safety margin, keeping in mind any additional features or constraints relevant to your project.

Here are some well-regarded brands in the industry:

  • Mean Well: One of the most recognized brands in the LED power supply industry, Mean Well offers a wide range of products suitable for both indoor and outdoor applications. Their units often come with features like overcurrent protection, dimming capabilities, and high efficiency.
  • Tridonic: A global leader in lighting technology, Tridonic offers LED drivers and power supplies that cater to various lighting solutions, from simple setups to advanced smart lighting systems.
  • Philips Advance Xitanium: Philips is a well-known brand in the lighting industry, and their Xitanium series of LED drivers are known for reliability and performance. They cater to both indoor and outdoor LED applications.
  • Osram: Another giant in the lighting industry, Osram offers a range of LED drivers and power supplies suitable for various applications, including architectural and street lighting.
  • LIFUD: Specializing in LED drivers, LIFUD is known for its high-quality products that cater to both commercial and residential LED lighting solutions.
  • MOSO: This brand offers a variety of LED drivers, especially for outdoor and industrial applications. Their products are known for durability and performance.
  • TDK-Lambda: With a history in power electronics, TDK-Lambda offers a range of power supplies and LED drivers suitable for various applications, emphasizing reliability and advanced features.
