Description:
Introduction: The Rising Influence of 2 Watt LED in High Power Lighting
2 watt LEDs, with their unassuming size and significant energy efficiency, have carved a niche in the realm of high power lighting solutions. Ideal for applications where space is at a premium but performance cannot be compromised, these LEDs represent the pinnacle of lighting innovation.
Key Features of 2 Watt LED High Power Solutions
- Efficiency: 2w LEDs stand out for their ability to deliver high luminescence with minimal energy consumption, marking a leap forward in sustainable lighting.
- Compact Design: Their small footprint makes them perfect for led light pcb designs, where space is a critical consideration.
- Durability: Engineered for longevity, these LEDs reduce the need for frequent replacements, contributing to their cost-effectiveness.
- Versatility: From commercial to residential applications, 2 watt LEDs illuminate a wide range of settings with precision and reliability.
Applications: Where 2 Watt LEDs Shine the Brightest
The application spectrum of 2 watt LEDs spans from intricate electronic devices requiring precise lighting to architectural features where they add aesthetic and functional value. Their adoption in solar-powered devices also underscores their role in green technology solutions.
Benefits: The Bright Side of Opting for 2 Watt LEDs
Choosing 2 watt LEDs brings numerous advantages, including significant energy savings, reduced carbon footprint, and enhanced lighting quality. Their integration into led light pcb designs further demonstrates their adaptability, meeting diverse lighting needs with unparalleled efficiency.
Case Studies: Illuminating Success Stories with 2W LEDs
This section delves into real-world implementations of 2 watt LEDs, showcasing their transformative impact across various projects. Success stories from led manufacturers highlight how these LEDs have been pivotal in achieving innovative, efficient, and cost-effective lighting solutions.
User Testimonials: Glowing Reviews from the Field
Feedback from industry professionals who have embraced 2 watt LEDs offers valuable perspectives on their practical benefits. Testimonials emphasize the improved performance, sustainability, and creative possibilities enabled by these high power LEDs, solidifying their reputation in the electronics sector.
Conclusion: Embracing the Future with 2 Watt LED Technology
The exploration of 2 watt LEDs in high power applications paints a future where efficient, reliable, and versatile lighting solutions take precedence. As technology advances, the significance of these compact yet powerful LEDs in driving forward sustainable and innovative lighting designs is increasingly evident.
Call to Action
For those at the forefront of electronics manufacturing and design, integrating 2 watt LEDs into your projects represents a step towards embracing efficient, innovative, and sustainable lighting solutions. Explore the potential of these compact powerhouses and illuminate your work with their unmatched brilliance and efficiency.
Features
- 2W Power Rating: These LEDs operate at 2 watts, offering a higher brightness level compared to lower wattage LEDs, making them suitable for applications that require more intense illumination.
- Suitable for Illumination and Decorative Lighting: Their enhanced brightness makes them ideal for both practical lighting solutions and decorative purposes.
- Long Service Life: Typically, these LEDs have a lifespan of up to 50,000 hours, which reduces the need for frequent replacements and ensures long-term reliability.
- Low Luminosity Loss: They maintain their brightness over time with minimal luminosity loss, ensuring consistent light output throughout their lifespan.
- Variety of Emitting Colors: Available in different colors, these LEDs offer flexibility for various lighting design requirements and aesthetic preferences.
- Working Current: Designed to operate within a current range of 200-350mA, making them compatible with a variety of drivers and power supplies.
- Heat Sink Options: Can be provided with or without a heat sink. The use of a heat sink is beneficial for heat management, particularly important in higher power LEDs to maintain performance and longevity.
Applications
- General and Task Lighting: Ideal for residential and commercial lighting fixtures where brighter illumination is required, such as in kitchens, workspaces, or retail environments.
- Architectural and Decorative Lighting: Their high brightness and color variety make them suitable for architectural features, accent lighting, and creating ambiance.
- Outdoor and Landscape Lighting: Used in outdoor lighting solutions like garden lights, pathway lighting, and architectural highlights.
- Display and Retail Lighting: Suitable for illuminating display cases, shelves, and highlighting products in retail settings.
- Automotive Lighting: Employed in automotive headlights, interior lighting, and signal lights due to their brightness and compact size.
- Specialty Lighting Applications: Useful in studio lighting, photography, and areas where intense, focused lighting is needed.
- DIY Projects and Custom Lighting Solutions: Popular in DIY projects for their versatility and ease of integration into custom lighting designs.
Electrical-optical characteristics:
Article No
| color | material | wavelength
| apperance | v_typ | v_max | luminous_min | luminous_typ | degree |
|---|---|---|---|---|---|---|---|---|---|
BL-HP51ABGC-2W |
Ultra Bluish Green |
505 |
Water Clear |
11 |
80 |
130 |
125 |
||
BL-HP51APGC-2W |
Ultra Pure Green |
525 |
Water Clear |
11 |
100 |
150 |
125 |
||
BL-HP51AUBC-2W |
Ultra Blue |
470 |
Water Clear |
11 |
25 |
35 |
125 |
||
BL-HP51AUEC-2W |
Ultra Orange |
630 |
Water Clear |
6.5 |
60 |
70 |
125 |
||
BL-HP51AUW2C-2W |
Ultra Warm White |
3200k |
Water Clear |
11 |
80 |
120 |
125 |
||
BL-HP51AUWC-2W |
Ultra White |
6000k |
Water Clear |
11 |
100 |
150 |
125 |
||
BL-HP51AUYC-2W |
Ultra Yellow |
590 |
Water Clear |
6.5 |
60 |
70 |
125 |
Package configuration & Internal circuit diagram
All dimensions are in millimeters(inches)
Tolerance is +-0.25(0.01″) unless otherwise note
Specifications are subject to change without notice.
Partno description:
LEDs, Light Emitting diodes, which include various small kinds, such as 3mm, 5mm, 8mm, 10mm; round type, rectangular type square type, tower type, Oval led, elliptical, flat top; SMDs, high power led, piranha LEDs
More Information
Lens Color:
| Code | D | T | C | W | E | |
| Meaning | color Diffused | Color Tinted | Water Clear | Water Diffused | Orange diffused |
Absolute maximum ratings (Ta=25°C)
| Parameter | SR | LR | UR | UE | UY | UG | PG | BG | B | UB | UV | W | Unit |
| Forward Current I F | 25 | 25 | 25 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | mA |
| Power Dissipation P d | 60 | 60 | 60 | 65 | 65 | 75 | 110 | 110 | 120 | 120 | 120 | 120 | mW |
| Reverse Voltage V R | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | V |
| Peak Forward Current I PF (Duty 1/10 @1KHZ) | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 100 | 100 | 100 | 100 | 100 | mA |
| Operation Temperature T OPR | -40 to +80 | °C | |||||||||||
| Storage Temperature T STG | -40 to +85 | °C | |||||||||||
| Lead Soldering Temperature T SOL | Max.260+-5°C for 3 sec Max. (1.6mm from the base of the epoxy bulb) | °C | |||||||||||
Related Information
Applied for:
The LEDs described here are intended to be used for ordinary electronic equipment (such as office equipment,
communication equipment and household applications). Consult Betlux’s Sales in advance for information on
applications in which exceptional reliability is required, particularly when the failure or malfunction of the LEDs
may directly jeopardize life or health (such as in aviation, transportation, traffic control equipment, medical
and life support systems and safety devices).
CAUTIONS for Through-Hole LED Lamps
1. Application
The LEDs described here are intended to be used for ordinary electronic equipment (such as office equipment, communication equipment and household applications). Consult Betlux’s Sales in advance for information on applications in which exceptional reliability is required, particularly when the failure or malfunction of the LEDs may directly jeopardize life or health (such as in aviation, transportation, traffic control equipment, medical and life support systems and safety devices).
2. Storage
The storage ambient for the LEDs should not exceed 30℃ temperature or 70% relative humidity. It is
recommended that LEDs out of their original packaging are used within three months
For extended storage out of their original packaging, it is recommended that the LEDs be stored in a sealed
container with appropriate desiccant or in a desiccator with nitrogen ambient.
3. Cleaning
Use alcohol-based cleaning solvents such as isopropyl alcohol to clean the LED if necessary
4. Lead Forming & Assembly
During lead forming, the leads should be bent at a point at least 3mm from the base of LED lens. Do not use
the base of the leadframe as a fulcrum during forming.
Lead forming must be done before soldering, at normal temperature.
During assembly on PCB, use minimum clinch force possible to avoid excessive mechanical stress.
Soldering
When soldering, leave a minimum of 2mm clearance from the base of the base of the lens to the soldering point. Dipping the lens into the solder must be avoided.
Do not apply any external stress to the lead frame during soldering while the LED is at high temperature.
Recommended soldering conditions:
| IR Reflow Soldering (for SMD display) | Wave Soldering | Soldering Iron | |||
| Pre-Heat | 150-180°C | Pre-Heat | 100°C Max. | Temperature | 300°C Max. |
| Pre-Heat Time | 120sec Max. | Pre-Heat Time | 60sec Max. | ||
| Peak Temperature | 260°C Max. | SolderWave | 260°C Max. | Soldering Time | 3sec Max.(one time only) |
| Soldering Time | 10 sec Max. | Soldering Time | 5sec Max. | ||
Note: Excessive soldering temperature and/or time might result in deformation of the LED lens or failure of the LED
ESD(Electrostatic Discharge)
Static Electricity or power surge will damage the LED.
Suggestions to prevent ESD (Electrostatic Discharge):
n Use a conductive wrist band or anti-electrostatic glove when handling these LEDs
n All devices, equipment, and machinery must be properly grounded
n Work tables, storage racks, etc. should be properly grounded
n Use ion blower to neutralize the static charge which might have built up on surface of the LED’s
plastic lens as a result of friction between LEDs during storage and handling
ESD-damaged LEDs will exhibit abnormal characteristics such as high reverse leakage current,
low forward voltage, or “no light on” at low currents. To verify for ESD damage, check for “light on”
and Vf of the suspect LEDs at low currents.
The Vf of “good” LEDs should be>2.0V@0.1mA for InGaN product and >1.4V@0.1mA for AlInGaP
product.
Drive Method
An LED is a current-operated device. In order to ensure intensity uniformity on multiple LEDs connected in
parallel in an application, it is recommended that a current limiting resistor be incorporated in the drive circuit,
in series with each LED as shown in Circuit A below.
When selecting power for LED systems, it’s essential to understand several key parameters to ensure safe operation, longevity, and optimal performance. Here are some steps and considerations for LED power selection:
- Determine the Forward Voltage (Vf) of the LED(s):
Each LED has a forward voltage, which is the voltage at which the LED operates when the current is flowing through it. This value can typically be found in the LED’s datasheet.
- Determine the Forward Current (If) of the LED(s):
The forward current is the current at which the LED is designed to operate. Running an LED at higher than its rated current can reduce its lifespan and increase the heat it produces.
- Decide on the Configuration:
Series Configuration: When LEDs are connected in series, the forward voltages add up, but the current remains the same.
Parallel Configuration: When LEDs are connected in parallel, the forward voltage remains the same, but the currents add up. This configuration can be risky because if one LED fails or has a slightly lower forward voltage, it can cause the other LEDs to draw more current.
Calculate Total Power Requirements:
Power (W) = Total Forward Voltage (V) x Total Forward Current (A)
For example, if you have three LEDs connected in series, each with a forward voltage of 3V and a forward current of 20mA, the total power requirement would be:
Power = (3V + 3V + 3V) x 20mA = 9V x 0.02A = 0.18W
- Select an Appropriate Power Supply:
- Voltage Rating: The power supply voltage should match or slightly exceed the total forward voltage of your LED configuration.
- Current Rating: The power supply’s current rating should meet or exceed the total forward current of your LED configuration.
- Safety Margin: It’s a good practice to select a power supply that can provide at least 20% more power than your calculated requirement. This ensures the power supply isn’t operating at its maximum capacity, which can extend its life and ensure safer operation.
- Consider Additional Features:
- Dimming Capability: If you want to control the brightness of your LEDs, choose a power supply with dimming capabilities.
- Overcurrent and Overvoltage Protection: To protect your LEDs, select a power supply with built-in protection mechanisms.
- Thermal Management: Ensure that the power supply has adequate cooling, especially if it will be enclosed or in a location with limited airflow.
- Regulation and Efficiency:A power supply with good regulation will maintain a consistent voltage output despite variations in the load. High efficiency ensures minimal power is wasted as heat.
- Physical Size and Form Factor:Depending on where you plan to place the power supply, its size and shape may be critical factors.
In summary, when selecting power for LED systems, understanding your LED’s requirements and the configuration you plan to use is essential. Then, pick a power supply that meets those needs with some added safety margin, keeping in mind any additional features or constraints relevant to your project.
