3mm Bi-Level LED CBI (11×4×10 mm), Dual-Position Circuit Board Indicator

The 3mm Bi-Level LED CBI is engineered for compact, multi-status indication in modern electronic devices where board space is limited but reliability is critical. Built in a bi-level configuration, this indicator provides two vertically stacked LED positions, enabling clear two-stage signaling within a single compact footprint.

Designed with versatility in mind, this CBI is available in many color combinations including single-color, bi-color, and tri-color LED options—ideal for displaying multiple states such as ON/OFF, warning/normal, or multi-step status signals.

Constructed using a UL 94V-0 rated PA66 housing, the unit ensures flame-retardant performance, long-term durability, and excellent optical contrast. Its pre-formed leads guarantee accurate PCB alignment, simplifying assembly and delivering consistent illumination performance across both LED levels.

Key Features

✔ Bi-Level Indicator Structure

A space-efficient design featuring two vertically stacked LED positions, providing a compact way to show dual alerts or two-step indicators.

✔ 3mm LED Package

Standard 3mm LED format ensures compatibility with existing electronic designs and maintains strong illumination output.

✔ Multiple Color Options

Available combinations include:

• Single-color (Red, Green, Yellow, Blue, White)

• Bi-color (Red/Green, Red/Yellow, Green/Yellow, etc.)

• Tri-color configurations

This flexibility enhances functional signaling in multi-state circuits.

✔ Broad Color Pairing Flexibility

The product line includes combinations of:

• Blue + Blue

• Blue + Green

• Blue + Yellow

• Green + Green

• Green + Red

• Red + Yellow

• Red + Amber

• Red + Green

• White + White

• RGB-style variations (RG, YG, etc.)

• Single-LED + Empty (X) for single-indicator CBI layouts

This wide color catalog provides exceptional flexibility for OEMs designing multi-status indication systems.

✔ High-Contrast Black Housing

The black CBI housing boosts indicator visibility by reducing reflection and improving contrast—especially important in bright industrial or commercial environments.

✔ Pre-Formed Leads for PCB Accuracy

Ensures consistent alignment during automated or manual assembly, improving production efficiency and reducing placement errors.

✔ Long-Life LED Chips

Stable, uniform illumination with minimal degradation over time.

✔ Industrial-Grade Build

• UL 94V-0 rated PA66 housing

• Halogen-free

• RoHS compliant

Suitable for global electronics manufacturing standards.

✔ Compact 11×4×10 mm Dimension

Optimized for high-density panel layouts and tight PCB spaces.

Product Selection Guide

Applications

The 3mm Bi-Level LED CBI (11×4×10 mm) is ideal for:

Industrial & Commercial Equipment

• Multi-status signal indicators

• Process equipment status windows

• Machine control panels

Communication & Test Instruments

• Vertical indicator stacks

• Signal monitoring systems

• Multi-stage test device indicators

User-Interface & Consumer Electronics

• Switch and keypad backlighting

• Power or mode status indicators

• Audio/visual equipment indicators

Compact Display Modules

• Instrumentation clusters

• Modular multi-point indicators

• Portable device signaling

Benefits

Space Saving

Bi-level design reduces PCB footprint while providing two separate indicator points.

Enhanced Visibility

High contrast and uniform brightness ensure the indicator can be seen clearly from multiple angles.

Flexible Design Options

Support for many LED color combinations enables custom signaling logic.

Reliable Performance

Built with high-grade materials for long service life and consistent electrical performance.

Why Choose This 3mm Bi-Level CBI?

This indicator offers a powerful combination of compact size, strong optical performance, and structural reliability—making it a preferred choice for engineers designing modern, multi-status electronic systems.
