1.8mm LED CBI, Dual-Level – Compact, High-Density Circuit Board Indicator
The 1.8mm LED CBI, dual level is engineered for compact, multi-status indication in modern electronic equipment where PCB space is limited but visibility and reliability are essential. This compact indicator uses a dual-level CBI design, enabling two vertically aligned LED positions in one small footprint. For customers seeking a space-saving yet highly effective indicator solution, this 1.8mm LED CBI offers outstanding performance, long operating life, and excellent color uniformity.
Its dual-stacked LED configuration allows designers to show two independent status signals—such as standby/run, warning/normal, power/activity—within the same localized display region. With its black PA66 housing, the indicator provides high contrast, making the ON/OFF states clear even in bright environments.
Key Features
Compact 1.8mm LED package for high-density panels
The 1.8mm LED CBI, dual level is designed for applications where space is at a premium. The miniature LED size enables dense population on instrument panels, telecom equipment, medical devices, and compact consumer electronics.
Dual-level CBI architecture
The two-level structure provides:
-
Two independent LED positions
-
Multi-status capability
-
Reduced PCB footprint
-
Better vertical visual alignment for stacked displays
This allows engineers to replace two separated indicators with one integrated module.
Pre-formed leads for accurate PCB installation
Each dual-level LED indicator features pre-formed, right-angle leads, ensuring:
-
Perfect seating on panel holes
-
Precise LED-to-panel alignment
-
Reduced assembly labor time
-
No mechanical stress on the PCB during installation
High-contrast black housing
The matte black PA66 housing enhances optical clarity by absorbing ambient light rather than reflecting it. This ensures:
-
Highly visible ON/OFF indication
-
Consistent color appearance
-
Improved readability in industrial lighting
Durable and safe materials
-
UL 94V-0 flame-retardant PA66
-
Halogen-free
-
RoHS compliant
These attributes make the product suitable for global production requirements, including industrial, medical, and commercial environments.
Long-life LED chip
The integrated LED provides:
-
Stable brightness
-
Low power consumption
-
Extended operational lifespan
Engineers can count on reliable performance for long-term assemblies or mission-critical applications.
Applications
The 1.8mm LED CBI, dual level is ideal for compact, multi-function indication across a wide range of industries:
Miniature status indicators
Used in small-scale electronics requiring precise visual feedback.
Multi-status or multi-function panels
Perfect for indicating combinations of:
-
Power
-
Network status
-
Alarm
-
Diagnostic conditions
Stacked indicator arrays in industrial instruments
Ideal for test equipment, laboratory instruments, and monitoring devices.
Compact display modules & signal towers
Supports applications where several indicators must fit into narrow vertical spaces.
Switch and keypad backlighting
Low-power, directional light output makes it excellent for compact UI elements.
Portable or handheld device indicators
The small size and strong durability allow integration into:
-
Handheld analyzers
-
Meters
-
Controllers
-
Battery-operated devices
Color Combinations (Summary)
The 1.8mm Dual-Level LED CBI supports a wide variety of color options, including:
-
Red
-
Green
-
Yellow
-
Blue
-
Bi-color combinations (RG, RY, GY, GB, etc.)
-
Tri-function options (multi-color per level)
-
Single-color or mixed-color setups per level
This allows highly flexible design choices for OEM production, instrumentation, and custom control panel layouts.
Why Choose a Dual-Level 1.8mm LED CBI?
1. Saves PCB Space
Two indicators are integrated vertically, reducing PCB area while maintaining multi-signal visibility.
2. Improves Panel Organization
Stacked LED indicators provide clear visual hierarchy for multi-status systems.
3. High Reliability
Durable housing + long-life LED chips ensure years of stable performance even in industrial environments.
4. Flexible Electrical Design
Available in:
-
Common anode
-
Common cathode
-
Independent channel operation
5. Easy Installation
Pre-bent leads remove manual alignment errors and speed up assembly.
User Testimonials
✔ Industrial Control Manufacturer
“The dual-level 1.8mm LED CBI significantly reduced PCB size in our control modules. The contrast of the black housing is excellent—even under strong ambient light.”
✔ Telecommunications OEM
“We use these indicators for multi-status network cards. The pre-formed leads save assembly time and ensure perfect alignment every time.”
✔ Consumer Electronics Developer
“For our compact handheld device, these indicators provide clear signaling without consuming much panel space. Highly recommended.”
Conclusion
The 1.8mm LED CBI, dual level is a high-efficiency, space-saving indicator designed for dense electronic assemblies. With its durable housing, long-life LEDs, compact footprint, and wide color availability, it is an ideal choice for engineers designing advanced control panels, compact instrumentation, compact consumer devices, and multi-status indicator systems.
If you are looking to upgrade your equipment visibility while reducing PCB footprint, this dual-level 1.8mm LED CBI delivers exceptional performance, versatility, and durability.
