1.8mm Quad-Level Circuit Board Indicator (CBI) – Compact, High-Density LED Solution for Multi-Status Displays
The 1.8mm LED CBI, Quad Level indicator is engineered for applications where compact size, precise alignment, and multi-status signaling are essential. As modern electronics continue to demand slimmer, smarter, and more space-efficient visual indicators, the quad-level circuit board indicator has become an indispensable component for manufacturers and engineers worldwide. Featuring a 1.8mm ultra-slim LED package, four vertically stacked indicator levels, and a robust PA66 housing, this module delivers exceptional reliability and clarity even in high-density panel environments.
In the world of compact electronic system design, the need for clear, vertically aligned status indication is growing. The 1.8mm LED CBI meets this need with engineered precision, offering a top-view configuration and 10×7×7mm housing that optimizes PCB space while maintaining excellent optical output. Whether used in instrumentation, communication hardware, handheld devices, or industrial controls, its multi-level indicator design enhances user interfaces with meaningful visual feedback.
Key Features of the 1.8mm Quad-Level Circuit Board Indicator
1. Compact 10×7×7mm Top-View Design
Designed specifically for modern compact electronics, the 1.8mm CBI features a small footprint that fits easily into dense layouts. The quad-level configuration allows four stacked indicators in the vertical direction, significantly reducing board space compared to using separate LEDs.
2. Slim 1.8mm LED for High-Density Applications
The ultra-slim 1.8mm LED package is perfect for devices requiring small, precise light points such as portable equipment, testing devices, and miniature control panels. Despite its small size, it provides strong illumination and excellent uniformity.
3. Pre-Formed Leads for Accurate PCB Alignment
Each level of the quad-indicator features pre-formed leads, ensuring perfect alignment and easy installation. Engineers gain consistent positioning and reduced assembly error while improving production efficiency.
4. High-Contrast Black Housing
The PA66 black housing enhances contrast and makes each indicator level vivid and easy to read. This is especially beneficial in bright environments or under backlighting conditions where clarity is essential.
5. Long-Life LED Chip Technology
Built with high-stability LED chips, the quad-level module ensures long service life, consistent luminous output, and dependable performance even in continuous-use applications.
6. Industrial-Grade Material and Safety Ratings
-
UL 94V-0 PA66 flame-retardant housing
-
Halogen-free materials
-
Fully RoHS compliant
These qualities ensure safe integration into consumer, commercial, and industrial equipment worldwide.
Applications of the 1.8mm Quad-Level CBI LED Indicator
Thanks to its compact design, quad positioning, and high visibility, this 1.8mm indicator is ideal for:
• Multi-Step Status Indication
Four independent LED levels allow intuitive step or stage indication such as:
-
Battery level indicators
-
Signal strength indicators
-
Multi-state progress indicators
• Dense Instrumentation and Control Panels
The slim LED structure fits easily into:
-
Laboratory instruments
-
Measurement and calibration equipment
-
Medical devices
• Communication and Testing Equipment
The quad-view indicator is perfect for real-time diagnostics, signal states, and device alerts in:
-
Telecommunication modules
-
RF testing equipment
-
Protocol analyzers
• Compact Display Modules
Ideal for:
-
Tower indicators
-
Embedded indicator stacks
-
Portable device signaling
• Consumer and Industrial Electronic Indicators
Used widely in:
-
Smart appliances
-
Home automation panels
-
Industrial controllers
-
Automation modules
Benefits of Using the 1.8mm Quad-Level Circuit Board Indicator
1. Space-Saving Vertical Stacking
The quad-level design reduces the number of PCB footprints required for multi-status displays by 75% compared to using four individual LEDs.
2. Enhanced Readability
The black housing enhances LED visibility, improving user interpretation and response time.
3. Long-Term Reliability
Stable LED chips and robust housing materials ensure long operational life with minimal maintenance.
4. Flexible Integration
Suitable for through-hole mounting, compatible with automated insertion processes, and easy to design into various board layouts.
5. Multi-Color Options
Available in:
-
Single color
-
Bi-color
-
Tri-color
-
Four-color (RGBY)
This makes it adaptable for complex signaling systems.
Case Study: Instrumentation Panel Upgrade
A testing equipment manufacturer upgraded from single-level LEDs to the 1.8mm Quad-Level CBI to solve limited display space in handheld instruments.
Results:
-
Reduced PCB indicator area by 60%
-
Increased number of status signals from 8 to 32 without expanding device size
-
Improved operator readability in bright lab environments
The upgrade also lowered manufacturing costs due to simplified PCB routing and assembly.
User Testimonials
Electronics Engineer – UK
“The 1.8mm quad-level indicator helped us redesign a control module with much higher status visibility, without increasing enclosure size. Perfect alignment and durability.”
Purchasing Manager – USA
“Reliable supply, excellent quality, and consistent LED output. The quad-stack design saves space and simplifies our panel designs significantly.”
Product Designer – Germany
“We use this component in compact portable devices. The small footprint and sharp contrast make it ideal for modern UI lighting.”
Conclusion
The 1.8mm Quad-Level Circuit Board Indicator is a powerful, compact lighting component engineered for today’s demanding electronic designs. With its vertical stack design, high visibility, long-life LEDs, and wide application coverage, it enhances any project requiring dense, multi-status visual feedback. Whether used in industrial equipment, communication modules, measurement devices, or consumer electronics, this CBI solution provides unmatched efficiency and clarity.
Upgrade your device interface with a modern, space-optimized quad-level indicator—engineered for performance, reliability, and design flexibility.
