A Guide to Understanding LED Lighting Terminology for Installers

/ FAQ / By

Introduction

For LED lighting installers, understanding key technical terms and specifications is essential for ensuring efficient installation, optimal performance, and customer satisfaction. Whether working on residential, commercial, or industrial projects, knowing the right terminology helps in selecting the best LED fixtures, drivers, and controls for different applications. This guide explains the most important LED lighting terms that every installer should know.A Guide to Understanding LED Lighting Terminology for Installers

1. LED Performance Metrics

1.1 Luminous Flux (Lumens – lm)

  • Measures the total light output from an LED source.
  • Higher lumens indicate brighter light.
  • Example: A 100W incandescent bulb produces around 1600 lumens, while a 15W LED can provide the same brightness.

1.2 Illuminance (Lux – lx)

  • Defines how much light reaches a surface per square meter.
  • 1 lux = 1 lumen per square meter.
  • Used for calculating lighting requirements in different environments (e.g., office lighting: 300–500 lux, warehouse lighting: 150 lux).

1.3 Luminous Efficacy (lm/W)

  • Measures how efficiently an LED converts electricity into light.
  • A higher lm/W ratio means better energy efficiency.
  • Example: A 150 lm/W LED is more efficient than a 100 lm/W LED.

1.4 Correlated Color Temperature (CCT – Kelvin/K)

  • Describes the color appearance of LED light.
  • Lower CCT (2700K–3500K) = Warm White (yellowish, cozy).
  • Mid CCT (4000K–5000K) = Neutral White (natural daylight feel).
  • Higher CCT (6000K–6500K) = Cool White (bluish, bright).

1.5 Color Rendering Index (CRI – 0 to 100)

  • Measures how accurately an LED light displays colors compared to natural light.
  • 80+ CRI is common for general lighting.
  • 90+ CRI is preferred for retail, photography, and medical lighting.

2. Electrical and Technical Specifications

2.1 Wattage (W) and Power Consumption

  • Indicates how much electricity an LED fixture uses.
  • LEDs consume less power than traditional lighting while delivering the same brightness.

2.2 Input Voltage (V)

  • Determines the operating voltage range of an LED fixture.
  • Low voltage (12V/24V DC) – Used for strip lights, automotive, and landscape lighting.
  • Line voltage (110-277V AC) – Used for residential and commercial lighting.
  • High voltage (347-480V AC) – Used in industrial and street lighting.

2.3 LED Driver

  • A power supply that converts AC to DC to regulate LED performance.
  • Constant voltage drivers (e.g., 12V/24V) – Used for LED strips and signage.
  • Constant current drivers (e.g., 350mA/700mA) – Used for downlights and high-power LEDs.

2.4 Dimming Compatibility

  • 0-10V Dimming – Common in commercial lighting for smooth brightness control.
  • TRIAC/Phase-Cut Dimming – Used in residential LED dimmable bulbs.
  • DALI (Digital Addressable Lighting Interface) – Smart lighting control for large buildings.

2.5 Power Factor (PF)

  • Indicates how efficiently an LED fixture uses electrical power.
  • PF > 0.9 is ideal for commercial and industrial installations.

3. LED Fixture Types and FeaturesA Guide to Understanding LED Lighting Terminology for Installers

3.1 Beam Angle

  • Determines how wide or narrow the light spreads.
  • Narrow beam (10°–30°) – Used for spotlights and accent lighting.
  • Medium beam (40°–60°) – Ideal for general lighting applications.
  • Wide beam (90°–120°) – Used in warehouses and large areas.

3.2 Ingress Protection (IP Rating)

  • Defines protection against dust and water.
  • IP20 – Indoor use only.
  • IP65 – Water-resistant, used for outdoor lighting.
  • IP67/IP68 – Waterproof, used for submerged and harsh environments.

3.3 Impact Protection (IK Rating)

  • Measures resistance against mechanical impact.
  • IK08 – Resistant to minor impacts.
  • IK10 – Maximum protection for vandal-proof lighting.

3.4 Lifespan (L70 Rating)

  • LED lifespan is defined by when brightness decreases to 70% of original output.
  • Example: L70 @ 50,000 hours means after 50,000 hours, brightness is still at 70%.

3.5 Smart LED Features

  • Motion Sensors – Automatically turn on/off based on movement.
  • Tunable White – Adjusts color temperature (e.g., 2700K to 6000K).
  • RGB and RGBW – Provides color-changing capabilities.
  • Wi-Fi & Bluetooth Control – Enables smartphone or voice control via Alexa or Google Assistant.

4. Installation and Safety Standards

4.1 UL, CE, and RoHS Certifications

  • UL (Underwriters Laboratories) – North American safety standard for LED fixtures.
  • CE (Conformité Européenne) – Required for LED products sold in Europe.
  • RoHS (Restriction of Hazardous Substances) – Ensures LEDs are free from harmful materials like lead and mercury.

4.2 Heat Dissipation and Thermal Management

  • Aluminum heat sinks and ventilated designs prevent LED overheating.
  • Overheated LEDs lose efficiency and lifespan.

4.3 Emergency Backup (Battery Systems)

  • Required in exit signs, emergency pathways, and power failure situations.
  • Emergency LED drivers provide backup power for at least 90 minutes.

Conclusion

For LED installers, understanding these key lighting terms and technical specifications ensures proper selection, installation, and maintenance of LED systems. Whether working on residential, commercial, or industrial projects, mastering LED terminology helps improve energy efficiency, safety, and lighting performance.
